Traditional T-Series 7 inch Window Fan

  • Patented electronic shutter system ensures quiet, trouble free operation
  • Shutter open/fan off mode
  • Low sound levels
  • Easy fit connector Top Socket, standard on all models
  • Designed for single or double glazing up to 32mm thick

Product Overview

Ventilation Type
Commercial Ventilation
Product Range
Traditional T-Series Window
Ducting/Connection Size

UK’s No. 1 Commercial Fan

The T-Series fan range is fitted with a Vent-Axia M-Tech motor, developed to improve performance, lower running costs and maintain the T-Series’ rugged reliability. A patented speed control pack is simply plugged in one of 3 positions to provide low, medium or boost speed matching the fan performance to the requirements of the installation.

Instantaneous Shutter

With energy saving in mind T-Series Fitting Kits are supplied complete with an integral instantaneous automatic louvre shutter concealed behind the interior grille. It operates on both extract and intake and at any angle of mounting. When the fan is used with a T-Series or Ecotronic controller, the shutter can be set open with the fan motor switched off to provide natural ventilation without the security risk of an open window.

Top Socket

A connector Top Socket is standard on all T-Series fans allowing fast and trouble-free mains connection.

Easy Cleaning

Integrated component design allows all parts to be dismantled for cleaning without the use of specialist tools.


Motor purpose-designed. Suitable for running at any angle. Quiet running. Suitable for operation in ambient temperatures from -40°C to +50°C. Fitted with Standard Thermal Overload Protection (S.T.O.P.).

Supply voltage 220-240V/1/50Hz.

Window Kit

Designed for use in single or double glazing, most types of glass and materials up to 32mm thick. Greater thicknesses can be accommodated using Extended Fixing Rod Sets. Can also be mounted in a fixing plate or wall, in ducts or above ceilings.

5 years product warranty provided on units purchased from the 1st August 2018.

Product Downloads

Catalogue Pages


Traditional T-Series Controller
  • 3-speed operation
  • Finger-tip sliders
  • Double pole On/Off Switching
  • Extract/intake airflow direction
  • Sensor mode for use with suitable electromechanical switches
  • Shutter open / fan Off setting
  • Designed to meet IP20
  • BEAB approved
